EEV-EX14 Micro ATX Type6 COM Express Carrier Board

EEV-EX14

Micro ATX Type6 COM Express Carrier Board

  • Micro ATX Form Factor
  • Accept BCM and others COM Express Type 6
    Compatible CPU Modules
  • VGA/LVDS/HDMI/DisplayPort
  • Audio Interface
  • 1 PCIex16, 1 PCIex4, 1 PCIex1 Slot
  • 4 SATA, 2 COM, 8 USB (Up to 4 USB 3.0), 8-bit GPIO
  • Mini-PCIe Card with SIM Card Slot, Express Card/54
  • Type 6 Pin-out
System
Form Factor Micro ATX (uATX)
I/O
Expansion 1 x PCIex16
1 x PCIex4
1 x PCIex1
1 x Express Card
1 x Mini PCIe
USB 8 x USB 2.0, 4 x USB 3.0, 4 x USB External
SATA 4 x SATA II Onboard
COM Port 1 x RS-232/422/485
1 x RS-232
1 x LPT
1 x RS232/422/485 external, 1xRS232 on board
Video 1 x Display Port
1 x VGA
1 x HDMI
1 x LVDS
1 x LVDS on board
Audio Mic-In, Line-In and Line-Out
MIO 1 x IrDA
Other 1 x PS2/ KB & MS, 1 x SDIO, 2 x LAN, 1 x 8-bit GPIO
Mechanical and Environment
Power Requirement +9 ~ +19V
ACPI Single Power ATX Support S0, S3, S4, S5
ACPI 3.0 Compliant
Power Type AT/ ATX
Operating Temperature 0 ～ 60°C （32 ～ 140°F）
Storage Temperature -20 ～ 80°C （-4 ～ 176°F）
Operating Humidity 0 ～ 90％ Relative Humidity, Non-condensing
Dimensions (L) x (W) 9.6" x 9.6" (243.84mm x 243.84mm)

* All product specifications and product images are subject to change without notice. Last update: 8/30/2017

Document
Datasheet
Manual
Model Name Description
EEV-EX14 uATX COMe Type 6 Eval Carrier Board
* EEV-EX14-A2R compatible with ESM-BYT, ESM-QM87
** EEV-EX14-A3R compatible with ESM-KBLH, ESM-SKLH, ESM-KBLU, ESM-SKLU, ESM-APLC
ACC-ESMSKLH-CL-1R COMe Heatsink with Fan for ESM-SKLH H=43.5mm
ACC-ESMKBLH-CL-1R COMe Heatsink with Fan for ESM-KBLH H=45.7mm
ACC-ESMSKLU-CL-1R COMe Heatsink with Fan for ESM-SKLU/ESM-BKLU H=50.5mm
ACC-ESMSKLU-SK-1R COMe Heatsink Only for ESM-SKLU/ESM-KBLU H=35.5mm
